Sun | Oracle 7079395 600 Watt Power Supply (X3-2/X4170-M3)
Sun | Oracle 7079395 600 Watt Power Supply (X3-2/X4170-M3)
Sun
original product. Product in stock, available immediately.
Our Price:
£
150.00
Availability::
Usually Ships in 24 Hours
Product Code:
7079395
Qty:
Description
Technical Specs
Extended Information
Sun | Oracle 600 Watt Power Supply (X3-2/X4170-M3).
Sun
Part Number
7079395
.
Original
Sun
Product.
Artesyn/Emerson AA27020L
600 Watt Power Supply
Servers
Sun Fire X4170 M3
Sun Server X3-2, X4-2
Oracle Server X5-2
Oracle Server X6-2, X6-2M
Oracle Advanced Support Gateway X3-2, X4-2, X5-2, X6-2
Oracle Database Appliance X3-2, X4-2, X5-2
Oracle Database Appliance X6-2HA, X6-2M, X6-2S
Private Cloud Appliance X5-2
Oracle Virtual Compute Appliance X3-2, X4-2
Oracle Private Cloud Appliance Expansion Rack
Disk Arrays
Oracle FS1-2 Flash Storage System
Miscellaneous Systems
Oracle Server X6-2 for Communications
7079395
Type A256
AC Input Power Supply
Specification 7038480
UL 60950-1 2nd Edition
EN 60950-1 2nd Edition
February 2014
AC Input
100-240Vac
50-60Hz
7.2A Max
DC Output
+12V
+12Vsb
47.3A
2.7A
Efficiency
115V
10% Load
75%
20% Load
85%
50% Load
89%
100% Load
87%
230V
10% Load
83%
20% Load
90%
50% Load
94%
100% Load
91%
Notes
Power Supply Efficiency affects the current draw in AC
Watts from the branch circuit. As efficiency increases,
the current draw in AC Watts decreases.
To calculate maximum theoretical current draw in AC Watts,
multiply the maximum power supply output in DC Watts by
the reciprocal of the power supply efficiency.
Theoretical values are typically higher than published values
which are based on measured outputs under controlled test
conditions.
Sun
original product.
All items tested by our experienced team of technicians and pulled from working systems.
In stock, ready to ship.
Item is refurbished with 90 days warranty, extended warranty options available.
Same-day and next day delivery available.
